One Bike To Rule All Trails
Stumpjumper 15 EVO is here to obliterate every trade-off in the trail game. Devour bumps like a big bike? Check. Short-travel control, playfulness, and efficiency? Double check. How about a heaping helping of personalization to make it perfect for the only rider who really matters—you? Check, check, check.
At a Glance
- Use: Trail
- Frame: FACT 11m carbon, SWAT Door integration, adjustable Trail Geometry
- Suspension: Front: 160mm RockShox Lyrik Select+ fork
Rear: 145mm RockShox Super Deluxe Select+ shock w/ GENIE
- Drivetrain: SRAM GX Eagle AXS Transmission
- Wheels: Roval Traverse HD Alloy wheels w/ DT Swiss 370 hubs
- Weight: 15.26 kg (33 lb, 10.3 oz)
TECHNICAL SPECIFICATIONS
Frameset
- Seat Binder: Alloy, 38.6mm
- Frame: FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- SWAT: SWAT 4.0 internal downtube storage
Suspension
- Rear Shock: All New Rockshox Super Deluxe Select + GENIE, RCT damper with (LSC) Low Speed Compression, GENIE adjustable airspring, rebound adjust, 210x55mm
- Fork: Rockshox Lyrik Select+, 29" 160mm (S2-S6); 150mm (S1), DebonAir+ air spring, Charger 3.1 RC2 damper with HSC and LSC, rebound adjust, 15x110mm
Brakes
- Front Brake: SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm Centerline Rotor
- Rear Brake: SRAM Maven Silver, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 200mm Centerline Rotor
Drivetrain
- Shift Levers: SRAM AXS Pod Controller w/discrete clamp
- Bottom Bracket: SRAM DUB Threaded Wide
- Rear Derailleur: SRAM GX Eagle AXS Transmission
- Crankset: SRAM GX Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline
- Chain: SRAM GX Eagle Transmission 12-Speed Flattop Chain
- Cassette: SRAM XG-1275 Transmission 12-Speed 10-52t
Wheels & tires
- Front Tire: Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29X2.4
- Rear Tire: Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
- Front Wheel: Roval Traverse 29" Rim, hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370 Hub, 15x110mm, 28h, Sapim Force Spokes
- Rear Wheel: Roval Traverse Rim, hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370 Hub, 12x148mm, 28h, Sapim Force Spokes, S1-S2: 27.5", S3:-S6: 29"
- Inner Tubes: Standard, Presta Valve
Cockpit
- Stem: Specialized, 35mm Clamp, 35mm Reach
- Seatpost: Bike Yoke, Revive Max 3.0, 34.9, S2: 125mm, S3: 160mm, S4: 185mm, S5-S6: 213mm
- Saddle: Bridge Comp, Hollow Cr-mo rails 155/143
- Grips: Deity Lockjaw, Lock On, 32mm OD, 133mm Length, Black
- Handlebars: Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep.
- S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
Weight
- Weight: 15.26 kg (33 lb, 10.3 oz)
- Weight Size: S4
