2023 Turbo Vado 4.0 ST
$5,600.00 Incl. tax
Add to cart
2023 Turbo Vado 4.0 ST
Specialized
(0)

2023 Turbo Vado 4.0 ST

$5,600.00 Incl. tax
In stock

Consider Vado your high-performance transportation bike, getting you where you’re going with an unmatched combination of speed, reliability, and confidence. Read more.

Product description

Whether you load it up with your stuff, or jump on and go, commute to work, or ride to the gym, Vado’s full power and huge range will get you from ‘point A’ to ‘point B’ ASAP.

The Specialized Vado has everything you need for e-powered transport. It brings a balanced nature to the way it handles and superior levels of comfort. This is a true class leader of its type.

TURBO: The heart of the Vado is its Turbo technology, an advanced and integrated electric bike system that delivers an unequaled combination of power, natural feel, anti-theft functions, training tips, and a full-function bike computer.

POWERFUL: It’s you, just faster — it’s 4x You. The Turbo Full Power system senses the force you apply to the pedals and naturally quadruples it for an experience that makes getting up any hill or to any destination no sweat. Literally.

COMFORTABLE AND CONFIDENT: Body position and handling are optimized to deliver unsurpassed riding comfort, confidence, and control. Powerful hydraulic disc brakes reign in your speed, while larger tires provide maximum traction for turning and stopping.



SMOOTH: Stay comfortable in the saddle with an 80mm front suspension fork, higher volume tires, and a plush suspension seat post that smooths harsh bumps from points A to B.

SECURE: Vado has anti-theft lock built right into the bike. Prevent would-be bike thieves by disabling the motor with a press of a button so no one can turn on the motor without your phone connected to the Specialized app or your personalized pin. The Vado’s battery locks in the bike or can be easily taken with you. And if anyone tries to move your bike an alarm will sound. Beat it, thieves.

The speed limit at which the motor will stop supporting may vary significantly by region and is based on local requirements. It may also affect range: a higher speed limit may result in less range.

  • Turbo Full Power 2.0 motor and 710Wh battery offer an unparalleled riding experience, providing a smooth, seamless, and shockingly quiet amplification of your efforts, up to 25 km/h. The integrated controller responds to your pedal inputs resulting in intuitive amplification of your efforts with an incredibly natural feel.
  • MasterMind and Specialized app - The MasterMind display reveals all relevant info about your ride and allows real-time tuning of support levels. MasterMind seamlessly integrates with the Specialized app for range optimization tools, advanced tuning, on-ride diagnostics, and more.
  • Proven Smooth Efficiency - We designed a custom testing mechanism to analyze bumps at even the smallest frequency to increase comfort and vision. That precision, paired with a suspended seatpost, higher volume tires, and an 80 mm suspension fork, will flatten roads before your eyes.
  • Turbo System Lock - Use the Specialized app to disable your bike’s motor and activate the motion sensor alarm. Once locked, the motor cannot be enabled again except by the owner.
  • Fully Integrated Removable and Lockable Downtube Battery - Easy to charge, easy to secure.
  • Equipped with DRYTECH Fenders, LED front and rear lights, and 27kg capacity rear HD Rack. The rear rack is compatible with child bike seats, and the bike is also rated to pull a thru-axle trailer.
  • Long-Range - With a ride-anywhere range, go up to 90 miles (145 km) or 6.5 hours on a single charge (eco mode).

TECHNICAL SPECIFICATIONS

E-bike
Charger: Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Wiring Harness: Custom wire harness
UI/Remote: MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
Motor: Specialized 2.0, 70Nm torque, custom tuned motor, 250W nominal
Battery: Specialized U2-710, alloy casing, state of charge display, 710Wh
Frameset
Seat Binder: Alloy, bolt-type, 34.9mm
Frame: E5 Aluminum, bottom bracket motor mount, fully integrated & lockable downtube battery, internal cable routing, lock and front rack mount
Suspension
Fork: SR Suntour MobieA32, 80mm travel, lockout, fender-mounts, integrated light mount
Brakes
Front Brake: SRAM Level, 2-piston caliper, hydraulic disc, 180mm
Rear Brake: SRAM Level, 2-piston caliper, hydraulic disc, 180mm
Drivetrain
Chainrings: Praxis, 48T, 104BCD
Crankset: Custom alloy forged crankarms
Chaincase: Custom chaincover
Chain: KMC e11S, 11-speed w/ Missing Link™
Shift Levers: SRAM NX, 11-speed
Rear Derailleur: SRAM NX, 11-speed
Cassette: SRAM PG-1130, 11-speed, 11-42t
Wheels & tires
Rims: 650b disc, double-wall alloy, pinned, 32h
Rear Hub: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes: DT Swiss Industry
Front Tire: Pathfinder Sport Reflect, 650Bx2.3
Rear Tire: Pathfinder Sport Reflect, 650Bx2.3
Front Hub: Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Inner Tubes: Standard 40mm SV 650Bx1.75-2.4
Cockpit
Grips: Body Geometry Women's Contour
Saddle: Bridge Sport, Steel rails, 155mm
Stem: Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp
Handlebars: Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm
SeatPost: Spring suspension, alloy, 40mm travel, 30.9mm, 2-bolt clamp, 34.9mm sleeve
Accessories
Fenders: Specialized DRYTECH fenders, 65mm width, aluminum fenderstay
Headlight: Lezyne Ebike Hecto E65, 210 Lumen, 12V
Bell: Simple bell
Taillight: Spanninga Commuter Glow XE, 12V
Pedals: Specialized Commuter w/ grip tape & reflectors
Kickstand: Specialized kickstand, 40mm mount
Rack: Specialized rack, MIK HD interface, built-in pannier mounts, 27kg max load
Bike Lock: Turbo System Lock
Weight
Weight: 26.4kg (58 lb, 3.2 oz)
Weight Size: MD

GEOMETRY

  S M L XL
Crank Length 170 170 170 170
Handlebar Width 680 680 680 680
Stem Length 60 60 75 75
Saddle Width 155 155 155 155
Seatpost Length 350 350 400 400
Reach 423 444 464 481
Bike Standover Height 618 617 617 626
Seat Tube Angle (Virtual) 75.5 75 74.5 74
Toptube Length (horizontal) 585 615 645 675
Headtube Length 135 150 165 190
Seat Tube Length 400 450 460 500
BB Height 285 285 285 285
BB Drop 70 70 70 70
Fork Rake/Offset 44 44 44 44
Stack 625 639 652 676
Wheelbase 1160 1186 1212 1239
Fork Length (full) 480 480 480 480
Trail 96 96 96 96
Front Center 699 724 750 777
Chainstay Length 470 470 470 470
Headtube Angle 68 68 68 68
